Auto Bed-Leveling Z-probe for Makerfarm Prusa i3 with E3Dv5 hotend

?
Creation's quality: 0.0/5 (0 votes)
Evaluation of members on the printability, utility, level of detail, etc.
  • 119 views

3D model description

This is a slight remix of my earlier Z-probe holder for use with Marlin's Auto Bed-Leveling system. I recently installed an E3Dv5 hotend, and the original part was too short, so I lengthened it. This isn't the sturdiest design to begin with, so I would suggest using the shorter version if it will fit in your installation.

The instructions are the same as for the original:

http://www.thingiverse.com/thing:167430

3D printing settings

Print this part. Insert the "shoulder" of your servo into the hole at the end of the main arm. Take the "single-arm" actuator/accessory, place it so that it extends along the "Slot side" of the arm. Use some m2.5 screws to attach your switch to the slot on the end of the arm and secure with the small accessory screw.

Use with either Alex Borro's replacement x-carriage end, or my parametric version.

  • 3D file format: SCAD and STL
  • Publication date: 2021/01/30 at 01:15
