Anti-Vibration Spool Holder

20230508_142023.jpg Anti-Vibration Spool Holder
01.png Anti-Vibration Spool Holder
20230508_142135.jpg Anti-Vibration Spool Holder
20230508_142143.jpg Anti-Vibration Spool Holder
02.png Anti-Vibration Spool Holder
03.png Anti-Vibration Spool Holder
clamping_part.png Anti-Vibration Spool Holder
plastic_01.png Anti-Vibration Spool Holder
plastic_01.stl Anti-Vibration Spool Holder
clamping_part.stl Anti-Vibration Spool Holder
Advertising
Share
Add to
Make
?
Creation quality: 0.0/5 (0 votes)
Evaluation of members on the printability, utility, level of detail, etc.
  • 470 views
  • 1 like
  • 2 downloads
Licence CULTS - Private Use
Publication date 2023-05-08 at 13:01
Design number 1209552
3D design format
STL Folder details Close
  • clamping_part.stl
  • plastic_01.stl

Learn more about the formats
szotyishaker

szotyishaker

3D printer file info

3D model description

Upgrade your 3D printing experience with this custom-made Anti-Vibration Spool Holder. It is designed for the original Ender 3 V2 metal spool holder, but it can be mounted to anything. This 3D-printed holder is designed to reduce the vibrations that occur during filament feeding, resulting in a smoother printing process and better print quality. The two-part design includes a bearing holder and bolt mount that can be easily assembled with the following hardware:

1 piece of M10x120 DIN 933 hexagon bolt
2 pieces of ISO 7094 washers
2 pieces of ISO 4032 nuts
1 piece of DIN 1587 domed cap nut

The dimensions for the bearing are: width:W=9mm, outer diameter:D=30mm, inner diameter:d=10mm. Any ball bearing with these dimensions will fit.

3D printing settings

3D Printing Settings:

Material: PLA
Layer Height: 0.2 mm
Support: None
Print Speed: 50 mm/s
Nozzle Temperature: 200°C
Bed Temperature: 60°C
