AM8 MGN12 z-axis / extended x-axis 300 buildplate

?
Creation's quality: 5.0/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.
  • 👁 3.9k views
  • 7 likes
  • 118 downloads

3D model description

Modified AM8 and AM8 2020 x-axis parts. 400mm MGN12 rails used for z-axis. Relocated z-motor position for extended travel of the x-axis. Not entirely sure if a 300x300 bed will fit due to actual bed size measuring 310mm but a 300mm glass will definitely fit. Removal of 2040 z-axis supports may be necessary.

Included both normal size x mounts and anti backlash size mounts. Print the x-axis with supports on.

1 side of parts is included. Just mirror the part in your slicer for opposite side.

3D printer file information

  • 3D design format: STL Folder details Close
    • LZMotorM.stl
    • Xantibacksize.stl
    • Xstocksize.stl

    Learn more about the formats

  • Publication date: 2017/10/16 at 14:27

License

CC BY SA
