A²C²DC : An AC Cable Drag Chain for the Artillery SW X1 (late 2020)

Creation quality: 5.0/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.

3D model description

Hello, thanks to RodaskB, you will find here a remix of my drag chain design for the Artillery Genius that has been made for the Artillery SideWinder X1 V4 made from late 2020's.

There are apparently several designs of the heated bed for the SW-X1, so please make sure yours fit : AC cable should get out of the heated bed between approximately at 60-70mm of the heated bed closest corner (see picture).

Instructions for assembly are the same as on the Genius, except that the silicon "foldable" sleeve seems to be even worse on the SW-X1 than on the Genius.
If it is aged a bit I strongly recommend to remove it, and to let the cables directly in the Chain.
If it is already damaged : remove it and change it.

All parts should print without any supports.

*** First person that sends me nice pictures of definitive setup with a video in a Cults make will get a full refund on its Paypal ! Just ask me in private comments !!!***

If there is any issue, please contact me for an adaptation or ask for a refund, you will get your money back immediately.

3D printing settings

see instructions PDF

3D printer file information

  • 3D design format: PDF and STL Folder details Close
    • ACDC_Connector.stl
    • ACDC_Link.stl
    • ACDC_LinkLogo.stl
    • ACDC_Spring.stl
    • ACDC_Support_X1_late2020_V6.stl
    • README.pdf

    Learn more about the formats

  • Last update: 2021-03-02 at 16:32
  • Publication date: 2021-02-27 at 11:23
