608ZZ Bearing Hanging Filament Spool Mount v2.5

?
Creation's quality: 5.0/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.
  • 957 views
  • 1 like
  • 31 downloads

3D model description

Updated Designed: Instead of using a 3D printed arm for the spool, I decided to create a holder with a 6 inch bolt.

Alternative Design: https://www.thingiverse.com/thing:3029252

I designed this hanging spool mount to go under my workbench with my printers. I had lots of bearing leftover from the fidget spinner craze and decided to put them to use. Filament comes off the roll nice and smooth.

Required Components:
1 x 5/16 in.-18 tpi Zinc-Plated Hex Nut (25-Piece per Bag) - (Homedepot) - (https://is.gd/33W8Yd)
1 x 5/16 in. Zinc Nylon Lock Nut (15 per Pack) - (Homedepot) - (https://is.gd/e1HuBL)
1 x 5/16 in. -18 tpi x 6 in. Zinc-Plated Hex Bolt - (Homedepot) - (https://is.gd/gfU2Uu)
4 x 608ZZ Bearings
https://amzn.to/31AvjbX

Printed Components Needed:
1 x HangingSpoolHolder_Base_v2.stl
4 x HangingSpoolHolder_Bearing_Spacer_v2.5_x4.stl
1 x HangingSpoolHolder_45mm_End_Cap_v2.5.stl
1 x HangingSpoolHolder_35mm_End_Cap_v2.5.stl (optional)

All STLs are print-ready oriented.

  • 3D file format: STL
  • Last update: 2020/09/01 at 19:58
  • Publication date: 2020/02/05 at 16:07

License

CC BY NC SA
