3D model description
( Work in Progress )
This is the first REAL 3D printed lathe that work. I design it to fit almost every 3d printer. All the precision is control by a custom board arduino with NEMA17 step motor. In other therm, this is a CN lathe that can be converted in full CNC mini lathe. This lathe can turn soft material like wood, plastic, resin and some really soft metal.
How to build it :
https://www.youtube.com/watch?v=MFTKBYK-Bsc
https://www.youtube.com/watch?v=m9Os2xgqGZI
Fusion 360 link :
https://a360.co/3en9tfT (FINAL)
All the links for the parts are in the video description.
3D printing settings
Layer Height: 0.18
Wall Line Count: 7 (1.32 mm )
Top and Buttom Layers: 7
Infill : 35% ( Gyroid )
3D printer file information
-
3D design format: STL Folder details Close
- 5.08 13t v2.stl
- 5.08 40t v9.stl
- ASSEMBLE.stl
- BODY LINK.stl
- CARRIAGE.stl
- Corps22.stl
- Corps45.stl
- Corps46.stl
- DREMEL HOLDER.stl
- ELECTRONIC.stl
- LINK.stl
- LINK2.stl
- MOTOR MOUNT.stl
- PIVOT BODY.stl
- PIVOT IN.stl
- PIVOT OUT.stl
- Last update: 2020-06-22 at 23:24
- Publication date: 2020-04-30 at 15:56
