120mm Fan to 100mm A/C Duct Adaptor

?
Creation's quality: 5.0/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.
  • 1.8k views
  • 9 likes
  • 173 downloads

3D model description

An adaptor/reducer for a 120mm case fan to a 100mm diameter air conditioning duct.

Used on my fume cabinet for my RepRap Prusa Mendel. (Short description: http://www.youtube.com/watch?v=YKh6kgO77Us)

The A/C ducting is standard 100mm ducting, as used in range hoods and bathroom extraction fans.

The fan end is based off a standard 120mm Case Fan aperture and bolt pattern, such as: http://au.element14.com/sunon/kd1212pmb1-6a-gn/fan-standard-120mm-12vdc/dp/9606416

3D printing settings

Adaptor dimensions:
120mm x 120mm x 100mm high.

Mounting Holes:
4.5mm diameter holes, suitable for M4 Fasteners. The holes are counterbored for a M4 washer. (Not shown in my photos)

I printed mine with:
0.3mm layer height
2 perimeters
3 solid layers
10% infill

Feel free to reduce the layer height, however this will increase the print time, and it's a long print.

It has been mounted in a cantilever position with the weight of the ducting hanging off of it for 6 months now, and hasn't had any problems.

If you can check your gcode before printing, ensure that the 100mm cylindrical section is printed as a solid wall. I reduced the wall thickness to 1.35mm in this model to allow the wall to be printed in ~3 perimeters. This should reduce the printing time from the original version which printed the inner and outer walls as two concentric walls with a small gap between them.

  • 3D file format: STL
  • Publication date: 2019/04/25 at 16:54

Tags

Creator

License

CC BY NC
