Tonic Table Lamp

?
Creation quality: 5.0/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.

3D model description

Tonic is a table lamp that has the particularity of being a luminous silhouette. Its shape arises from the intersection of two truncated cones, one opposite the other. Base and diffuser are merged and become a single object, especially when switched on. The lower support becomes a diffusive element, while the diffuser shields the excessive brightness. The difference in brightness between the diffuser and the base, and the gradient generated on the surfaces of these elements, gives volume to the object.

Dimensions when assembled: 190 x 190 x 240 mm.
A 200x200x200 printing volume will be enough.

Material is PLA, but any other option should work too.
Don't stretch the model, it requires a specific hole diameter to fit the lamp holder.
To be completed, it just requires an E14 lamp holder and an E14 Led Bulb.

The three components are held together by the socket of the lamp holder.
What's simpler?
Check the rest of the collection on my profile!


3D printing settings

Notes: Model thickness is 0,8 mm for all the components.
For a good lighting result it is suggested to generate the wall with wall line count: 2, using a 0.4 mm nozzle and a layer height of 0.2 mm.

It is important to set the seam in only one point, so as to have a very clean surface.
No support is required. No post-printing is required.

3D printer file information

  • 3D design format: STL Folder details Close
    • TONIC_BASE.STL
    • TONIC_DIFFUSER.STL
    • TONIC_Top.STL

    Learn more about the formats

  • Publication date: 2022-09-29 at 15:35
