Modular Cube Storage Shelf

Creation quality: 5.0/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.

Licence CULTS - Private Use
Publication date 2023-09-26 at 20:41
Design number 1475838
3D design format
STL Folder details Close
  • Honeycomb Panel.stl
  • Shelf Clip 2 Way.stl
  • Shelf Clip 3 Way.stl
  • Shelf Clip 4 way.stl
  • Solid Panel.stl

Learn more about the formats


3D printer file info

3D model description

This is a modular shelf that can be expanded upon as much as you'd like. The side panels can also be scaled on the x and y axis to make each individual cube as big as you want. I've allowed a 0.2mm tolerance on the shelves (5mm slots and 4.8mm panels). I'd suggest printing a 2 way clip and a panel to test how the tolerances are on your printer. You can adjust the tolerance by adjusting the z thickness of the panels.

I did print the clips without supports but that will be dependent on the capabilities of your printer. You may have to turn on supports for the horizontal slots. This is something else you should test before printing all of the pieces. I've included solid and honeycomb panels so you can build yours with any combination of the two that you want. Glue is not required as everything should be held together by friction.

As mentioned, you can expand this system to be as large as you want. The example I printed consists of the following parts though:

2x 4 Way Clips
8x 3 Way Clips
8x 2 Way Clips
12x Honeycomb Panels
2x Solid Panels

3D printing settings

4 Walls
10% Infill
Supports are optional depending on your printer capabilities.
