Geometric Desk Organizer
3D model description
This geometric Desk Organizer is heavily optimized for easy printing! No supports.
All parts fit onto a standard print bed at once. 20x25cm
It's not only modern in design, but also offers great functionality.
- Pens pens pens
- Post-It pocket with additional room
- Paperclip bowl (optional magnetic)
- 3 USB slots
- Tape Dispenser (3D printed blade that works!)
(optional magnetic attachement to base)
You only need some glue to combine both tape wheel parts. For perfect and easy aligment, use one or two Allen Key size 3 and put them through the given holes.
Don't want to bother with magnet inserts?
Just ignore them, the design works great without them too!
Magnet inputs are entirely invisible.
3D printing settings
0.2mm layer height
PLA works great
Optional Magnet Inserts:
Either use the prepared .3mf file with PrusaSlicer for a fully configured print setup. It includes a print stop at perfect height!
Or configure it yourself as follows:
If printed at 0.2mm layer height, define a single print stop at layer nr 166.
Insert all 6 magnets with some glue and wait a few minutes for them to hold onto the print properly. (Otherwise the magnets may be attracted by the Extruder during print)
Then continue to finish the print.
6 x Neodym Magnet Discs (6mm x 1.5mm) (snug fitting)
6 x Neodym Magnet Discs (5mm x 1.5mm) (easy fitting or downscaling)
Glue for magnets
3D printer file information
- Design number: 225941
3D design format: 3MF and STL Folder details Close
- Last update: 2021-04-23 at 16:16
- Publication date: 2020-11-10 at 19:59
