Funnel Suspension Lamp

?
Creation quality: 5.0/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.

3D model description

Funnel is a suspension lamp that uses simple geometries to achieve a diffusive light and direct one. The lamp is composed by three elements, a first element of the body to which is added the second that shields the excess light emitted, and a large and circular part that acts as a horizontal element delimiting the light source. The compactness of the volumes make it suitable to be placed above furnishing elements such as tables and coffee tables, to provide concentrated lighting.

Dimensions when assembled: 195 x 195 x 130 mm.
A 200x200x200 printing volume will be enough.
Material is PLA, but any other option should work too.
Don't stretch the model, it requires a specific hole diameter to fit the lamp holder.

To be completed, it just requires an E14 lamp holder and an E14 Led Bulb.

Check the rest of the collection on my profile!


3D printing settings

Notes: Model thickness is 0,8 mm for diffuser and 1,2mm for the base.
For a good lighting result it is suggested to generate the wall with wall line count: 2, using a 0.4 mm nozzle and a layer height of 0.2 mm.

At least for the diffuser, it is important to set the seam in only one point, so as to have a very clean surface.

No support is required. No post-printing is required.

3D printer file information

  • 3D design format: STL Folder details Close
    • Funnel_ext_righe_0,8.STL
    • Funnel_int_0,8.STL
    • Funnel_piatto.STL

    Learn more about the formats

  • Publication date: 2022-09-29 at 15:20
