Fully Customizable General Purpose Handles

?
Creation quality: 5.0/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.

3D model description

Here we have some fully customizable general purpose handles. There are two variants: one with a single screw fixing point and one with dual screw fixing points.

We really like guppyk’s Handle - All Purpose, Four Sizes, but we needed something slightly different. Rather than modify guppyk's model, we chose to create a similar design in OpenSCAD that is fully customizable.

You may also like...

If you like this design, you may also like our Fully Customizable General Purpose Handle Grip.

Thingiverse Cusomizer App

We recommend you use OpenSCAD to customize this design. However, you can also customize it online via the Thingiverse Customizer App:

OpenSCAD Customizer Options

You can customize everything from the size and position of the screw holes to the overall dimensions of the handle and the style of the bevel.

Single Point Variant

OpenSCAD Customizer Options:

Screw

  • Screw_Hole_Diameter - Screw hole diameter
  • Screw_Direction - Screw from front or rear

Front Screw

  • Screw_Head_Hole_Diameter - Screw head hole diameter
  • Screw_Material_Thickness - Material thickness (between screw head and base)
  • Screw_Countersink_Angle - Screw countersink angle (82 and 90 are common)

Rear Screws

  • Screw_Hole_Depth - Depth of screw hole

Stem

  • Stem_Material_Thickness - Thickness of stem (X and Y axis)
  • Stem_Height - Height of stem (Z axis)

Handle

  • Handle_Grip_Width - Width of grip (X and Y axis)
  • Handle_Height - Height of handle (Z axis)
  • Square_Handle - Should the handle be square?

Base

  • Base_Enabled - Should a base be added?
  • Base_Lip_Width - Width of base lip (X and Y axis)
  • Base_Lip_Height - Height of base lip (Z axis)

Bevel

  • Bevel_Radius - Radius of bevel
  • Bevel_Rounded - Should bevel be rounded?

Dual Point Variant

OpenSCAD Customizer Options:

Screws

  • Screw_Distance - Distance between the screws
  • Screw_Hole_Diameter - Screw hole diameter
  • Screw_Direction - Screw from front or rear

Front Screws

  • Screw_Head_Hole_Diameter - Screw head hole diameter
  • Screw_Material_Thickness - Material thickness (between screw head and base)
  • Screw_Countersink_Angle - Screw countersink angle (82 and 90 are common)

Rear Screws

  • Screw_Hole_Depth - Depth of screw holes

Handle

  • Handle_Material_Thickness - Thickness of handle (X and Y axis)
  • Handle_Height - Height of handle (Z axis)
  • Handle_End_Length - Handle end length (in addition to Handle_Material_Thickness)

Hand Hole

  • Hand_Hole_Width - Width of hand hole (X axis)
  • Hand_Hole_Depth - Depth of hand hole (Y axis)

Bevel

  • Bevel_Radius - Radius of bevel
  • Bevel_Rounded - Should bevel be rounded?

Versions

Single Point Variant

  • 1.2 (25 Mar 2022) - Added options for rear screw (Screw_Direction and Screw_Hole_Depth)
  • 1.1 (1 Dec 2020) - Improvements for Thingiverse Customizer
  • 1.0 (4 Nov 2020) - Initial version

Dual Point Variant

  • 1.2 (25 Mar 2022) - Added options for rear screws (Screw_Direction and Screw_Hole_Depth)
  • 1.1 (1 Dec 2020) - Improvements for Thingiverse Customizer
  • 1.0 (4 Nov 2020) - Initial version

Printing

Recommended slicer settings:

  • Resolution: 0.1mm - 0.2mm
  • Infill: ~50% for soft filaments, such as PLA (could probably be lower for tougher filaments, such as ABS)
  • Supports: Doesn't Matter
  • Rafts: Doesn't Matter

For round single point handles, you may wish to consider randomising the start position of each layer to avoid a Z seam. In Cura this option is called Z Seam Alignment.

For small single point handles, you may need a print with a brim.

Attribution

This work, Fully Customizable General Purpose Handles was inspired by guppyk’s Handle - All Purpose, Four Sizes.

Whilst some of the models included in the project may appear similar to the models from guppyk's project, the code and files in this project do not include any of the code or files from guppyk's project. All of the STLs in this project are original and were generated using code that was developed, in full, by Code and Make (i.e. from the .scad file included in this project).

Although we do not believe this project can strictly be considered a derivative (or 'remix' in Thingiverse parlance) of guppyk's project, we believe it is fair and proper to give credit to guppyk for the original design concept. For this reason, we have marked this project as a 'remix' of guppyk's project on Thingiverse to show our appreciation.

Handle - All Purpose, Four Sizes by guppyk is licensed under the CC BY license by guppyk.

License

The "Fully Customizable General Purpose Handles" models (.stl) are licensed under the CC BY license by Code and Make.

The "Fully Customizable General Purpose Handles" code (.scad & .json) is licensed under The MIT License by Code and Make.

We are proud to offer content to you absolutely free.

We love to create free content for you. As you might imagine, it takes a lot of time. Supporters help us fund materials and equipment to create future projects and tutorials. To show your appreciation, please use the link below:

https://codeandmake.com/support

We thank you so much for your support!

3D printer file information

  • 3D design format: SCAD and STL Folder details Close
    • codeandmake.com_General_Purpose_Handle_Dual_Point_v1.2.scad
    • codeandmake.com_General_Purpose_Handle_Dual_Point_v1.2_-_Large_(115mm)_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Dual_Point_v1.2_-_Large_(115mm)_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Dual_Point_v1.2_-_Large_Rounded_(115mm)_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Dual_Point_v1.2_-_Large_Rounded_(115mm)_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Dual_Point_v1.2_-_Large_Very_Rounded_(115mm)_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Dual_Point_v1.2_-_Large_Very_Rounded_(115mm)_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Dual_Point_v1.2_-_Medium_(100mm)_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Dual_Point_v1.2_-_Medium_(100mm)_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Dual_Point_v1.2_-_Medium_Rounded_(100mm)_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Dual_Point_v1.2_-_Medium_Rounded_(100mm)_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Dual_Point_v1.2_-_Medium_Very_Rounded_(100mm)_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Dual_Point_v1.2_-_Medium_Very_Rounded_(100mm)_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Dual_Point_v1.2_-_Small_(85mm)_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Dual_Point_v1.2_-_Small_(85mm)_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Dual_Point_v1.2_-_Small_Rounded_(85mm)_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Dual_Point_v1.2_-_Small_Rounded_(85mm)_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Dual_Point_v1.2_-_Small_Very_Rounded_(85mm)_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Dual_Point_v1.2_-_Small_Very_Rounded_(85mm)_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Dual_Point_v1.2_-_X_Large_(140mm)_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Dual_Point_v1.2_-_X_Large_(140mm)_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Dual_Point_v1.2_-_X_Large_Rounded_(140mm)_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Dual_Point_v1.2_-_X_Large_Rounded_(140mm)_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Dual_Point_v1.2_-_X_Large_Very_Rounded_(140mm)_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Dual_Point_v1.2_-_X_Large_Very_Rounded_(140mm)_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2.scad
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Large_Round_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Large_Round_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Large_Round_Base_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Large_Round_Base_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Large_Round_Base_Rounded_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Large_Round_Base_Rounded_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Large_Round_Base_Very_Rounded_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Large_Round_Base_Very_Rounded_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Large_Round_Rounded_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Large_Round_Rounded_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Large_Round_Very_Rounded_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Large_Round_Very_Rounded_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Large_Square_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Large_Square_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Large_Square_Base_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Large_Square_Base_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Large_Square_Base_Rounded_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Large_Square_Base_Rounded_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Large_Square_Base_Very_Rounded_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Large_Square_Base_Very_Rounded_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Large_Square_Rounded_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Large_Square_Rounded_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Large_Square_Very_Rounded_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Large_Square_Very_Rounded_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Medium_Round_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Medium_Round_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Medium_Round_Base_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Medium_Round_Base_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Medium_Round_Base_Rounded_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Medium_Round_Base_Rounded_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Medium_Round_Base_Very_Rounded_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Medium_Round_Base_Very_Rounded_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Medium_Round_Rounded_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Medium_Round_Rounded_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Medium_Round_Very_Rounded_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Medium_Round_Very_Rounded_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Medium_Square_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Medium_Square_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Medium_Square_Base_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Medium_Square_Base_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Medium_Square_Base_Rounded_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Medium_Square_Base_Rounded_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Medium_Square_Base_Very_Rounded_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Medium_Square_Base_Very_Rounded_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Medium_Square_Rounded_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Medium_Square_Rounded_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Medium_Square_Very_Rounded_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Medium_Square_Very_Rounded_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Small_Round_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Small_Round_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Small_Round_Base_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Small_Round_Base_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Small_Round_Base_Rounded_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Small_Round_Base_Rounded_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Small_Round_Base_Very_Rounded_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Small_Round_Base_Very_Rounded_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Small_Round_Rounded_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Small_Round_Rounded_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Small_Round_Very_Rounded_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Small_Round_Very_Rounded_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Small_Square_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Small_Square_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Small_Square_Base_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Small_Square_Base_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Small_Square_Base_Rounded_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Small_Square_Base_Rounded_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Small_Square_Base_Very_Rounded_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Small_Square_Base_Very_Rounded_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Small_Square_Rounded_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Small_Square_Rounded_-_Rear_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Small_Square_Very_Rounded_-_Front_Screws.stl
    • codeandmake.com_General_Purpose_Handle_Single_Point_v1.2_-_Small_Square_Very_Rounded_-_Rear_Screws.stl

    Learn more about the formats

  • Last update: 2022-03-25 at 23:35
  • Publication date: 2020-12-17 at 17:38
    ?
    Published to Thingiverse on: 2020-11-04 at 19:06

License

CC BY

Tags

Creator

Designs 45
Downloads 2.6k
Followers 28

Your support will help us to bring you more awesome, free projects and tutorials:

https://codeandmake.com/support

Issue with this design? Report a problem

Best 3D printer files of the Home category

Best sellers of the category Home


Add a comment


Would you like to support Cults?

You like Cults and you want to help us continue the adventure independently? Please note that we are a small team of 3 people, therefore it is very simple to support us to maintain the activity and create future developments. Here are 4 solutions accessible to all:

  • ADVERTISING: Disable your AdBlock banner blocker and click on our banner ads.

  • AFFILIATION: Make your purchases online by clicking on our affiliate links here Amazon.

  • DONATE: If you want, you can make a donation via PayPal.

  • WORD OF MOUTH: Invite your friends to come, discover the platform and the magnificent 3D files shared by the community!
