Free 3d model fixing spot led, mk25

Did you 3D print this model?

fixing spot led

3D model description

realization of a fixing assembly to install spots on sheet metal ( ex: kitchen hood) in abs for temperature resistance.

the spacer wedges the back of the spotlight

the box can be clipped onto the hubcap, if any

the nut jams the spotlight between the spacer and the housing

the plate has a hole with a flat (anti-rotation)

note

the housing without notches is mounted without hubcaps

3D printing settings

ABS ICE filament 1.75 mm Cura software

T° 250 nozzle, T° 80° plate

30% filling

quality thickness 0.20mm

speed 80

  • 3D model format: STL
