Coin Vault

?
Creation quality: 4.7/5 (16 votes)
Evaluation of members on the printability, utility, level of detail, etc.

3D model description

A one-of-a-kind, stylish coin vault with functional door pins. Comes in multiple, easy-to-print parts. Fantastic and fun gift for adults and children (assembly may involve small gears. Adult supervision recommended)

PDF assembly instructions included.

Metal nuts and bolts recommended for assembly. These may be found easily and cheaply in any hardware store or through Amazon (usually all sizes sold in a single box).

Fasteners:

  • 3x M3 Nut
  • 3x M3x16 bolt
  • 6x M3x8 bolt
  • 2x M3x20 bolt

3D printing settings

  • Dimensions: 9 x 8 x 8 cm
  • Recommended layer height: 0.1-0.2mm
  • Support: no support required (only exception being for the bolt holes on part #8)
  • In case the pins do not stick to the bed, try printing with a brim.
  • All parts pre-oriented for best printing results

Tolerances vary by printer type and calibration. If a moving part or a bolt hole is too snug, use a small file.

3D printer file information

  • 3D design format: PDF and STL Folder details Close
    • Box_back_v2.stl
    • Box_front_v3.stl
    • Box_top_v2.stl
    • Box_vent.stl
    • Door_back_v5.stl
    • Door_front_v3.stl
    • Door_mid_v4.stl
    • Gear_10Z_10mm.stl
    • Gear_10Z_5mm.stl
    • Gear_30Z_30mm_v2.stl
    • Handle.stl
    • Hinge spacer.stl
    • Pin.stl
    • Vault Box Assembly.pdf
    • Vault Door Assembly.pdf

    Learn more about the formats

  • Publication date: 2021-06-12 at 23:16

Copyright

©

Tags

Creator

Engineer, Tinkerer, Designer

Have requests, questions, or suggestions? Feel free to contact me!

Check my Thinverse for free stuff!

https://www.thingiverse.com/byzantium3d/designs
