Bathroom sink strainer

?
Creation's quality: 5.0/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.
  • 595 views
  • 37 downloads

3D model description

Customized version of http://www.thingiverse.com/thing:351541 . It fits our bathroom sink drains.

Created with Customizer! http://www.thingiverse.com/apps/customizer/run?thing_id=351541

The slots are intentionally narrow to capture small stuff. To test it fully open the faucet and make sure that the water do not accumulate in the sink beyond let's say an inch or two.

I print it in white PLA in upside down orientation and with support material from the printing bed. I used Simplify3D for slicing and played with the thin wall setting (in the Advanced tab) to have proper gap filling of thing walls of the strainer.

3D printing settings

Using the following options:

side_slit_top_margin = 7
outer_diameter = 27
filter_periodic_length = 2
filter_height = 3
main_cylinder_height = 20
head_diameter = 40
handle_upper_diameter = 0.01
filter_opening_ratio = 0.4
inner_diamter = 22
handle_lower_diameter = 0.01
head_cylinder_height = 1.2
handle_height = 0.01
gradient_height = 1
side_slit_bottom_margin = 0
side_slit_opening_ratio = 0.27
side_slit_periodic_length = 3
filter_beam_aspect_ratio = 0.6

  • 3D file format: STL
  • 3D model size: X 40 × Y 39.8 × Z 22.2 mm
  • Publication date: 2020/01/29 at 21:26
