Speedy "Red Midi Swept Wing"

Creation's quality: 5.0/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.

3D model description

This is a forward swept wing which you can use with the fuselage of the “Speedy Red Midi Wing”
The carbon rods pass all the way through, providing extraordinary
stability. You need one 8 mm tube and one 5mm tube, each 1000mm long.
These rods are so stiff and fit in so tightly, you don’t need to glue anything.
This makes changing a part very easy, in case it is broken or you want it in another color.
I havn’t had a chance myself to maiden it yet.

Recommended Print Settings
The wings are designed to print using 0.5 mm width, 0.3 mm height, 3 bottom and 3 top
layers, but one perimeter only.
Should you print thinner walls, the perimeter of the upper side will not stick well enough
to the perimeter of the inner stiffening construction.
If you apply thicker walls, the perimeters will not come out continuously in one
uninterrupted turn.
The layers must build up as if you were printing in spiral vase mode. Only then you get a
smooth surface on the upper side.
If unsatisfied with the results, try out 0.49 or 0.48 width in your slices settings. It
depends whether you use Cura, Slic3r, S3D or what yo have. I suggest you experiment with
some tests before printing the whole thing.

The second point is: Should you print lesser layer heights, the inner stiffening
construction will not connect well to the top and bottom layers. You will suffer a gap in

All wing parts: layer height =0,3mm, width =0.5 mm

wing: 1 perimeter, 3 bottom layers, 3 top layers, hollow
wing servo: 3 bottom layers, 3 top layers, hollow
elevon inner: 7 (!) bottom layers, spiral vase mode
elevon outer: 3 bottom layers, spiral vase mode
elevon joint: no bottom layer, spiral vase mode

airfoil: AR2610-S80 modified
wing span: 1000 mm
wing chord: 200/128 mm
aerodynamic center: 30 mm (12%)
overall weight: 730 g
wing weight 343 g (without components)
wing weight complete: 374
fuselage weight complet 356 g
fin weight 12 g
wing area: 16,6 dm²
wing loading: 44 g/dm²
longitudinal stability (Thies) STFs:
motor: Propdrive 28-36 1000KV
static thrust: 950 g (3S Lipo)
battery: Turnigy 1200 mAh 3S 40~50C Lipo
motor camber: tilted -4 degrees
side pull: none
propeller: Aeronaut CAM Aeronaut Carbon Classic 10 x 6"

3D printer file information

  • 3D design format: STL Folder details Close
    • Servosegment0.09.stl
    • elevon_appendix.stl
    • elevon_inner.stl
    • elevon_joint.stl
    • elevon_outer.stl
    • servo_mount_TGY-9018MG.stl
    • wing_center_brim_180.stl
    • wing_end.stl
    • wing_inner_brim_110.stl
    • wing_middle_brim_110.stl
    • wing_outer_110.stl

    Learn more about the formats

  • Publication date: 2018/01/22 at 11:50





I am constructing engineer for powerplants. Designing was allways my passion and I am glad, now as a pensioner, to have interesting challenges again.
