Star Wars ATST Walker - Ready to print - with instructions

?
Creation's quality: 5.0/5 (2 votes)
Evaluation of members on the printability, utility, level of detail, etc.
  • 👁 17.3k views
  • 62 likes
  • 50 downloads

3D model description

The model you can see on the pictures was printed with PLA 1.75 mm silver filament on an anycubic I3 mega printer with 0.1mm layers (printing temperature 200°C - base plate temperature 60°C). The scale of the model is about 1/30 and contains 36 unique parts. In order to assemble the parts, you're gonna need 19 CHC Screw M3 x 10 (ISO 4762) and 19 H Nut M3 (ISO 4762) as shown in the instruction manual. Feel free to contact me for further informations and your feedback.


3D printing settings

PLA Silver Filament
Printing temp 200°C
Base temp 60°C
Layers 0.1 mm
Supports - see instruction manual

3D printer file information

  • 3D design format: STL and ZIP Folder details Close
    • ATST.stl
    • ATST.zip

    Learn more about the formats

  • Last update: 2019/12/02 at 20:47
  • Publication date: 2018/07/01 at 14:17

Copyright

©

Tags

Creator

Designs 7
Downloads 102
Sales €799
Followers 39
Issue with this design? Report a problem

Collection associated with this 3D model


Makes created by the community

Best sellers of the category Game


Add a comment

16 comments

Hello, I would recommend ISO 4035 HM M8 nuts and DIN 6912 CHC M8x20 screws.

example here :

https://www.vis-express.fr/fr/vmx-chc-t-basse-a2-din-7984/40614-942629-vis-metaux-chc-btr-tete-bas-hexagonal-creux-5-8x20-filetage-total-inox-a2-3663072196377.html#/78-conditionnement-30_pieces

https://www.vis-express.fr/fr/ecrou-hm-inox-a4/37771-905489-ecrou-hexagonal-bas-hm-m8-inox-a4-3663072225077.html#/78-conditionnement-30_pieces

You may have to do some adjustments when putting the model together because the 256% upscaling for the screws and nuts is not perfect, but that should work. Let me know if you have a problem.

This printing is gonna be huge, please post pictures of it when it's done. Best regards.

Hi, and thanks for the great files for this AT-ST!

I plan on upscaling this to 256% to fit in with the scale of my Star Wars - The Black Series 6" action figures. What screws would you recommend for this upscaling?

Hola, no el interior de la cabina sirve para poner tuercas y fijar otras piezas. Es vacio. Un saludo.

Hola. Tiene interiores la cabina? O es solida?

1/50 scale would be 180mm tall but it's mentioned in the comments this is 280mm tall. If it's 280mm then the scale is way off. Can you please let me know the actual height of this model before I purchase it? I've had problems when scaling other models down in Cura where certain parts won't print properly. Thanks

Hello, did you receive the files I sent last saturday?

Ok, will do that next saturday. Best regards.

Also I'm a bit confused would you not just need to send me a peg the diameter of the screw? I can scale the peg to the same percentage as the rest of the model then. :)

Ok, I'll prepare you a multiple parts solid model (step format). I just need to see how I share it with you because it will be to big to send by E-mail. Best regards.

And no its not super small, the peg would be fine if i scaled it down with the rest of the parts. Multiple pieces over one solid model would be better for the purpose as i want to sla some parts for detail and fdm the rest. Thanks for the reply!

can i private message you on here?

No problem, I can e-mail it to you fi you give me an adress. What is the scale you want to use? If you want to make it a lot smaller, a plastic shaft won't work (the diameter will be to low), in this case I'll send you the full ATST model and you'll have to print it in one pièce, with supports, and it won't be articulated. I will not be available until friday, so I will probably send you that saturday or sunday. Best regards.

That would be great thanks, how would I obtain that? Would I have to re-download the file?

Hello, the model is about 280 mm tall (scale 1/50). If you want to scale it, you won't be able to assemble it with the standard screws. In this case, I can design a printable shaft to replace the screws, but you'll have to glue the parts to assemble it.

How tall is it when assembled? i want to print it for Legion so i need to scale it to the rest of the figures
