Micro FPV Tank - Inspired By Tiny Trak

Download free 3D model Micro FPV Tank - Inspired By Tiny Trak, janikabalinDownload free 3D model Micro FPV Tank - Inspired By Tiny Trak, janikabalinDownload free 3D model Micro FPV Tank - Inspired By Tiny Trak, janikabalin

Did you 3D print this model?

3D model description

You will need:
-2x 9g servo
-small PPM receiver
-1s or 2s battery
-micro AIO FPV camera (optional)
-1mm wire or paper clips
-8x3x4 bearings (2x for 4W version or 4x for 6W version)
-M3 screws (2x for 4W or 4x for 6W)

For the 4 Wheel Version print:
-4W Chassis
-2x Wheel Bearing
-2x Wheel Servo
-4x Tracks or 38x Track Link

For the 6 Wheel Version print:
-6W Chassis
-4x Wheel Bearing
-2x Wheel Servo
-4x Tracks or 38x Track Link

To join the track links I used 1mm paper clips.
To attach the servos to the chassis the two screw tabs on the servo need to be cut (it's shown on one of the pictures).
To attach the two wheels to the 9g servos take the arms that come with the servos and remove the arm part so you are left with only the round thing (also shown in the same picture).
For the bearing wheels push the 8x3x4 bearings into the wheel and screw it on the chassis with M3 screws.

  • 3D model format: STL
