IBOT Vr2.0 - The Simple Robot Model Kit

?
Creation's quality: 5.0/5 (2 votes)
Evaluation of members on the printability, utility, level of detail, etc.
  • 2.1k views
  • 18 likes
  • 128 downloads

3D model description

IBOT is the graceful successor to the original design. I took the proportions and style from Vr1 and expanded on every aspect of the 3d model. So whats new?

  • Articulated ball joints for the arms and legs.
  • Pivot joints for the elbows and knees
  • Improved details
  • Functional Hands to accommodate accessories.
  • Efficient modelling techniques (all pieces are designed with a flat face for easy printing & small parts ensure it can be printed on the tiniest of print beds)

I've put alot of love into this design and i hope it shows through. It's a great little weekend project and i'd love to see how you make it your own.


3D printing settings

Total Print Time for IBOT Alone - 15hr
Total Print Time for all pieces - 20hr

I personally used the following settings on all pieces.

Supports? only on Hands, Body, Pelvis
Rafts? Recommended
Infill? All pieces are hollow with the thick walls setting enabled
Resolution? I printed at 0.2mm layer thickness (200 microns)

Some light sanding maybe required depending on the resolution you use.

The ball joints are a tight but trust me they do fit.

IBOT is approximately 14cm tall when complete.

3D printer file information

  • 3D design format: STL Folder details Close
    • IBOT2_-_Ball_Pegs.stl
    • IBOT2_-_Biceps.stl
    • IBOT2_-_Body.stl
    • IBOT2_-_Booster_Pack.stl
    • IBOT2_-_But_Plug__Pelvis_.stl
    • IBOT2_-_Feet.stl
    • IBOT2_-_Femurs.stl
    • IBOT2_-_Forearm.stl
    • IBOT2_-_Hands.stl
    • IBOT2_-_Head.stl
    • IBOT2_-_Instruments_of_Death_1.stl
    • IBOT2_-_Instruments_of_Death_2.stl

    Learn more about the formats

  • Publication date: 2016/07/09 at 14:51

License

CC BY
