FPV Orca V2 - 800mm 3D Printed FPV Wing!
3D model description
The FPV Orca is our first model and was developed for FPV Free Flight. Its fuselage is derived from the wing profile and therefore offers excellent aerodynamics. Orca's stall speed is 55km/h and has a maximum speed of over 250km/h. In contrast, the print weight is only 217 grams with Regular PLA.
Orca V2 provides excellent cooling for the FPV system and Motor and you will not have any overheating problems. It is stable and as fast as a racing model and you can build the model with a single 5x500 mm Carbon Fiber Rod.
Orca V2 has a second service hatch so you can install and service your FC and other accessories. There is a lot of space inside of the fuselage for this.
Orca was developed for Regular PLA, but V2 is also fully compatible with LW-PLA, TPU, and PetG with its continuous printing technique. You can use PetG for high temperatures or LW-PLA when you want it to fly slower. LW-PLA also allows you to charge more batteries.
If you are interested in making your first FPV Freestyle Wing, you can visit our YouTube channel for detailed Build and Flight Videos: https://bit.ly/channel_sub
Troy MC Millan Also has a Great Video for Orca V2: https://youtu.be/K6xY-tMlYZU?si=tdAc8YORQ2yx8EER
PDF Guide: https://bit.ly/pdfguideorcav2
--- General Specs ---
Length : 365 mm
Wingspan : 800 mm
Print Weight : 217 gram
Flying Weight : 450-550 gram
Wing Area : 12.5 dm2
Wing Loading : 40g/dm2
Airfoil : MH 45 9.85%
Minimum 3D Printer Size: 150x150x150 mm
Material: Regular PLA (LW-PLA Compatible)
--- Download Included ---
Ready to print G-code files (G-codes need min 180x180mm print area).
User Guide (Detailed for assembling and printing).
Note: DJI Air Unit and Caddx Vista Canopies are not included in the files. Check the store to find Hatch Options. (Analog FPV Hatch included in the files. It has 30mm FPV Camera Mount)
--- Required Electronics ---
4ch+ Radio / FPV System
2205 2300kv Brushless Motor
1500 mAh 4S Lipo
2 pcs, 9g servos
Buy PowerPack: https://craycle.com/product/craycle-power-pack-orca/
- Longer Aileron Wing: https://cults3d.com/en/3d-model/various/longer-aileron-wing-for-fpv-orca-v2-stl-files
- Servo Protector: https://cults3d.com/en/3d-model/various/orca-v2-servo-protector
- Landing Sled (Coming soon...)
Join the Facebook Craycle Crafter Group to see other people's builds and share your works. You can also ask for help from Craycle Community: https://bit.ly/craftergroup
Follow Instagram to be updated: https://bit.ly/craycleinstagram
Subscribe Youtube for Build/Fight videos: https://bit.ly/channel_sub
3D printing settings
Please follow the instructions in the PDF User Guide.
Import Craycle Cura Profile: https://craycle.com/craycle-cura-profile/
0,2 Layer Height
Minimum 150x150x150 mm Bed Size
3D printer file information
- Design number: 411267
3D design format: STL and TXT Folder details Close
- Last update: 2023-05-21 at 13:10
- Publication date: 2021-04-25 at 13:08
