Ballista ballista

3D model description

This is the latest addition to the ball pitcher range.

The Ball Ball Ball, two springs project the ball. The idea came from a comment on my Facebook page.

The two springs combine their force on a rack to throw the ball along the barrel.

The loading is carried out by a lateral conduit, a piston operated by a lever brings the ball into the barrel.

An explanation of the assembly is to come.

Feel free to contact me for more information.

Be careful though, as the ball is propelled with a certain force, the ball could break objects or injure!

More projects:

https://cults3d.com/fr/utilisateurs/3d-fabric-jean-pierre/cr%C3%A9ations

Follow:

https://twitter.com/fabricejeanpier

3D printing settings

The main body is designed so that it does not need support, it is to avoid having to leave the barrel support and the side channel.

But most parts do not need support.

To have good mechanical characteristics, the axes are printed flat with supports.

  • 3D model format: STL
