Airsoft Folding Mini Launcher

?
Creation's quality: 5.0/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.
  • 5.5k views
  • 10 likes
  • 7 downloads

3D model description

Spanish/english

youtube in action

https://youtu.be/ZodiGAMuTlY

Instagram

https://www.instagram.com/xmoxix.td01

Hello!

This is a design of a mini airsoft launcher using Gas/CO2 shotgun cartridges, small, light and handy, easy to carry.

necessary:

*Gas or Co2 airsoft shotgun cartridges

example:

http://www.asiaairsoft.com/index_eproduct_view.php?products_id=6615

Note: Please note that the cartridge has to be the Gas or CO2 container.

Screws:

X2 : M3 x 30mm screw, cylindrical head with hexagonal recess.

X2: screw M3 x35mm, cylindrical head with hexagonal recess.

X4: self-locking M3 nut with hexagonal head

X1 Cylindrical pin din-6325, hardened, made of steel.

Dimension A: 2 mm; Dimension B: 30 mm

ENGLISH:

Hello!

This is a design of a mini launcher for airsoft uses Gas / CO2 shotgun cartridges, small, light and handy, easy to carry.

necessary:

  • Gas or Co2 airsoft shotgun cartridges

example:

http://www.asiaairsoft.com/index_eproduct_view.php?products_id=6615

Note: keep in mind that the cartridge has to be the Gas or CO2 container.

Screws:

X2: M3 x30mm screw, cylindrical head with hexagonal socket.

X2: M3 x35mm screw, cylindrical head with hexagonal socket.

X4: M3 hexagonal head self-locking nut

X1 Pin din-6325 cylindrical, tempered, steel.

Dimension A: 2mm; Dimension B: 30 mm.

3D printing settings

quality: 0.2mm

walls: 3mm

fill density: 20%

printing temperature: 210ºC . PLA.

printing plate temperature: 40ºC-60ºC.

Speed: 50mm/s - 80mm/s

  • 3D file format: STL
  • Last update: 2020/04/20 at 19:29
  • Publication date: 2020/04/03 at 12:52
