3-in-1 HO scale 1:87 railroad wagon

?
Creation's quality: 5.0/5 (6 votes)
Evaluation of members on the printability, utility, level of detail, etc.
  • 4.9k views
  • 16 likes
  • 387 downloads

3D model description

UPDATE:15.12.2018

I've added a version 2 of the car rail - it is a little bigger, as the original version does not support all different kinds of car.

Moreover, I've added a 0.3 mm high stripes to be printed in different color. Here is the example tutorial:

  1. Slice the stripes at 0.1 mm layer hight;
  2. Save the file at local hard drive.
  3. Open the file with text editor - notepad or better notepad++
  4. Hit CTRL+F to open the find window;
  5. Type Z0.600 - to find where the stripes layer begins;
  6. Jist befor the line with the Z0.600 command insert/type the following code:

M600 or M601 ;pause

M300 ;activate beeper

M104 S195 ;Sets target temperature for nozzle. In my case, I print with 195 deg, you can adjust it according to your filament;

M602 ;Resume SD card print from long pause.

  1. Save the file
  2. Load BLACK filament and start printing;
  3. At the end of layer hight 0.5 mm the printer will stop and beep
  4. Change the filamet to YELLOW
  5. Press RESUME PRINTING

And VIOLLA - you have a multi-color printing - black rails with nice yellow stripes.


Hello,

Actually, this is not my original design. I found this wonderful model here:

https://3d-modeli.net/3d-models/3d-modeli-transport-tehnika/zheleznodorozhnaja-tehnika/9699-vagon-avtovoz.html

and made it printable. I also changed the bogies, as the original ones are extremely detailed. I may also someday make them printable too.

I made it in several parts, so that we have a 3-in-1 cart:

  1. Container train cart;
  2. Flat platform cart - top part not ready yet!
  3. Car carrier.

The only difference is the top part. I've included a complete model, but with small number of polygons to help you in assembling the model, especially the lower railings.

Have fun, and don't forget to show us your prints of the model..

  • 3D file format: STL
  • Publication date: 2019/12/24 at 17:48

License

CC BY

Tags

Creator

Designs 51
Downloads 11.9k
Sales US$23
Followers 241
Issue with this design? Report a problem

Best sellers of the category Game


Add a comment

One comment

Can you upload a video showing the process of building the model?
