Tripod Phone Stand (no screw ! )

IMG_20201223_100021956-01.jpg Free STL file Tripod Phone Stand (no screw ! )・3D printing model to download
IMG_20201223_100208516_HDR-01.jpg Free STL file Tripod Phone Stand (no screw ! )・3D printing model to download
Tripod_assembly.png Free STL file Tripod Phone Stand (no screw ! )・3D printing model to download
ball_joint_screw.png Free STL file Tripod Phone Stand (no screw ! )・3D printing model to download
Frame.png Free STL file Tripod Phone Stand (no screw ! )・3D printing model to download
tightening_screw_01mm.png Free STL file Tripod Phone Stand (no screw ! )・3D printing model to download
Frame_up.png Free STL file Tripod Phone Stand (no screw ! )・3D printing model to download
Tripod_head_01mm.png Free STL file Tripod Phone Stand (no screw ! )・3D printing model to download
Ball_Joint_01mm.png Free STL file Tripod Phone Stand (no screw ! )・3D printing model to download
Tripod_center.png Free STL file Tripod Phone Stand (no screw ! )・3D printing model to download
Tripod_stand.png Free STL file Tripod Phone Stand (no screw ! )・3D printing model to download
Tripod_center.stl Free STL file Tripod Phone Stand (no screw ! )・3D printing model to download
Tripod_stand.stl Free STL file Tripod Phone Stand (no screw ! )・3D printing model to download
Frame.stl Free STL file Tripod Phone Stand (no screw ! )・3D printing model to download
Frame_up.stl Free STL file Tripod Phone Stand (no screw ! )・3D printing model to download
ball_joint_screw.stl Free STL file Tripod Phone Stand (no screw ! )・3D printing model to download
Tripod_head_01mm.stl Free STL file Tripod Phone Stand (no screw ! )・3D printing model to download
tightening_screw_01mm.stl Free STL file Tripod Phone Stand (no screw ! )・3D printing model to download
Ball_Joint_01mm.stl Free STL file Tripod Phone Stand (no screw ! )・3D printing model to download
Tripod_head_02mm.stl Free STL file Tripod Phone Stand (no screw ! )・3D printing model to download
Ball_Joint_02mm.stl Free STL file Tripod Phone Stand (no screw ! )・3D printing model to download
tightening_screw_02mm.stl Free STL file Tripod Phone Stand (no screw ! )・3D printing model to download
Tripod_head_03mm.stl Free STL file Tripod Phone Stand (no screw ! )・3D printing model to download
Ball_Joint_03mm.stl Free STL file Tripod Phone Stand (no screw ! )・3D printing model to download
tightening_screw_03mm.stl Free STL file Tripod Phone Stand (no screw ! )・3D printing model to download
ball_joint_screw_standard-threadright_handed.stl Free STL file Tripod Phone Stand (no screw ! )・3D printing model to download
Tripod_head_standard_threadright_handed.stl Free STL file Tripod Phone Stand (no screw ! )・3D printing model to download
Share
Add to
Make
?
Creation quality: 4.0/5 (5 votes)
Evaluation of members on the printability, utility, level of detail, etc.
  • 23.1k views
  • 142 likes
  • 1.7k downloads
  • 1 comment

Designer

Diezopfe

Diezopfe

3D model description

PROJECT PRESENTATION

This project is a tripod allowing to maintain a phone in all possible positions thanks to a ball joint.

The assembly is done without any screws, which however does not affect its robustness.

The goal for me is to create other supports that can accommodate this ball joint for other applications, such as in a car, for a camera stand, etc...

Enjoy printing !

#FIVERRCULTS

⚠⚠⚠ Used tolerance by default between parts is 0.1mm ⚠⚠⚠
If your printer can't achieve this tolerance for moving parts (especially screws), use the files named 0.2mm or 0.3mm that have bigger tolerances.

Assembly instructions

  • The legs of the tripod must be nested in the central part.
  • The upper part of the tripod fits into the base. Warm the base before inserting it to hold it in place firmly, or glue it.
  • The screw of the ball joint must be passed through the ball of the ball joint before screwing the ball on the frame. A little of glue may be necessary to prevent the screw from loosening over time.
  • Caution! The ball joint screw is screwed on the tripod in the trigonometric direction!
  • Insert the upper part of the chassis on the frame and use the nut to tighten.

Do you think I did a good job?

Feel free to comment what you think of this design and tell me how you use it!
If you want to help me, don't hesitate to visit my paypal. me for the price of a nice croissant !
=> https://paypal.me/DieZopfe

image-text

3D printing settings

Printer Brand: Creality
Printer Model:Ender 3
Raft:No
Support:Yes
Resolution: 0.2 max
Infill: 25%
Filament Material: PLA

3D printer file information

  • Design number: 292188
  • 3D design format: STL, TXT, and ZIP Folder details Close
    • Ball_Joint_01mm.stl
    • Ball_Joint_02mm.stl
    • Ball_Joint_03mm.stl
    • Frame.stl
    • Frame_up.stl
    • README_Model_details.txt
    • Tripod_center.stl
    • Tripod_head_01mm.stl
    • Tripod_head_02mm.stl
    • Tripod_head_03mm.stl
    • Tripod_head_standard_threadright_handed.stl
    • Tripod_stand.stl
    • ball_joint_screw.stl
    • ball_joint_screw_standard-threadright_handed.stl
    • step_files.zip
    • tightening_screw_01mm.stl
    • tightening_screw_02mm.stl
    • tightening_screw_03mm.stl

    Learn more about the formats

  • Last update: 2021-03-08 at 21:49
  • Publication date: 2021-02-12 at 15:35
    ?
    Published to Thingiverse on: 2020-12-23 at 11:16
