Triaxial Motorized

?
Creation quality: 5.0/5 (7 votes)
Evaluation of members on the printability, utility, level of detail, etc.

3D model description

This is a Motorized version of my original Triaxial Tourbillon Clock Make. The two major changes are that this version uses stepper motors to driver the carrier, and it incorporates the Triaxial Quartz Movement Upgrade. However, there are many other subtle differences from the original Triaxial design.

Here is a time lapse version of the design
https://youtu.be/so1m_iGdigE,
and a real-time video
https://youtu.be/2vyGcqjci-Q

It seems like Jacob and Co never makes the exact same watch twice. There are almost as many variations of Astromomia watch, as there are pictures of it on the web.I based this Motorized version on the model of the Jacob and Co. Astromomia watch in this video:
https://www.youtube.com/watch?v=qvx0jXbKkV0

Most of the clock face parts will be the same as those in the Quartz Upgrade, this design includes a version of the clock face (Clock Face w Embedded Numerals) that can be printed in 2 colors, where the second color determines the color of the numerals.

The Moon model is a remix from: https://www.thingiverse.com/thing:1014620
The Earth model is a remix from:
https://www.thingiverse.com/thing:17336
And the my original Triaxial make was a remix of A26's design:
https://www.thingiverse.com/thing:3061474
His design provided the inspiration for this design, however I have redesigned every part.


3D printing settings

Printer brand:
Prusa

Printer:
I3 MK3S

Rafts:
No

Supports:
Yes

Resolution:
1.5mm

Infill:
15%

Filament_brand:
Hatchbox

Filament_material:
PLA

3D printer file information

  • 3D design format: PDF, STL, and ZIP Folder details Close
    • 22x19x2 Spacer.STL
    • 2x1mm Bearing Spacer.STL
    • 8Tgear.STL
    • Astro_Motorized_Stepper.zip
    • Balance Spring Adjuster Ring.STL
    • Balance Spring.STL
    • Balance Wheel Spacer.STL
    • Balance Wheel.STL
    • Base 2 with Numerals - Base.STL
    • Base 2 with Numerals - Numerals.STL
    • Base 2.STL
    • Base Bottom.STL
    • Base Frame 2.STL
    • Base Main Gear 2.STL
    • Carrier 3.STL
    • Carrier Bearing Block 2.STL
    • Carrier Bottom.STL
    • Carrier Counter Weight Cover.STL
    • Carrier Counter Weight.STL
    • Carrier Crowngear 24T.STL
    • Carrier Drive Gear 45T 2.STL
    • Carrier Globe Gear 12T.STL
    • Carrier Globe Shaft half.STL
    • Carrier Globe Shaft.STL
    • Carrier Main Bearing Spacer.STL
    • Carrier Shaft 2 half.STL
    • Carrier shaft 2.STL
    • Carriertop Jewel Holder 2.STL
    • Earth North.stl
    • Earth South.stl
    • Escape Wheel.STL
    • Fork Frame 1.STL
    • Fork Frame 12T Gear 2.STL
    • Fork Frame 2.STL
    • Fork Frame 2a.STL
    • Fork Frame 40TGear.STL
    • Fork Frame Back.STL
    • Fork Frame Shaft 2.STL
    • Fork.STL
    • Gear Cap.STL
    • Hand Hour.STL
    • Hand Minute.STL
    • Jewel 17mm.STL
    • Jewel 8mm.STL
    • Jewel Carrier.STL
    • Minute Gear 72T 2.STL
    • Moon North.stl
    • Moon South.stl
    • Stepper Pinion 2.STL
    • T Frame Back.STL
    • T Frame Middle 2.STL
    • T Frame Middle b.STL
    • T Frame Top.STL
    • TE Face Bridge.STL
    • TE Face Drive Gear 24T 2.STL
    • TE Face Drive Gear 24T20T 2.STL
    • TE Face Face w Embedded Numerals - Face.STL
    • TE Face Face w Embedded Numerals - Numerals.STL
    • TE Face Face.STL
    • TE Face Hourgear1 Shaft 2.STL
    • TE Face Hourgear1.STL
    • TE Face Hourgear2a.STL
    • TE Face Hourgear2b.STL
    • TE Face Hourgear3.STL
    • TE Face Movement Cover Bottom.STL
    • TE Face Movement Cover.STL
    • TE Face Numerals.STL
    • TE Face Plate.STL
    • TE Face Spacer.STL
    • Triaxial Motorized Build Notes.pdf

    Learn more about the formats

  • Publication date: 2020-06-22 at 01:06

License

CC BY NC

Tags
