The Ergosaurus Rex (Poppy Ergo Jr with T-Rex 3D printed parts)

?
Creation's quality: 5.0/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.
  • 4.4k views
  • 13 likes
  • 149 downloads

3D model description

Turn your favorite small and low cost 6-degree-of-freedom robot arm into the King of the Jurassic Era !

Full description of this work can be found on our forum here: https://forum.poppy-project.org/t/poppy-ergo-jr-t-rex-grabber/2938

A little reminder of what is Poppy Ergo Jr
It works with Dynamixel XL-320 motors, and a Raspberry Pi for control.
It comes with three tools (end effector):

a lampshade
a grasper (the tool used to make the T-Rex jaw)
a pen holder
You can control the robot with Python (from a Jupyter notebook interface) or via Snap, a visual programming language similar to Scratch.

You can buy all pieces by yourself (BOM link), or buy robot without printed parts on one of Poppy distributors.

Assembly Guide
A full assembly guide is available on the online Poppy documentation.

About Poppy Project
Poppy is an interdisciplinary platform gathering beginners and experts, scientists, educators, developers and artists, that all share a vision: robots are powerful tools to learn and be creative.
The Poppy community develops robotic creations that are easy to build, customise, deploy, and share.

Useful Links:
GitHub repository (software and hardware)
Community forum to share things, ideas or ask help
Poppy project website
Education dedicated website (in french)


3D printing settings

Printer Brand:
MakerBot

Printer:
MakerBot Replicator 2

3D printer file information

  • 3D design format: STL Folder details Close
    • trex_alternative_arm_L.stl
    • trex_alternative_arm_R.stl
    • trex_arm_L.stl
    • trex_arm_R.stl
    • trex_head_lower.stl
    • trex_head_upper.stl
    • trex_leg_L.stl
    • trex_leg_R.stl
    • trex_tail.stl
  • Publication date: 2017/06/21 at 17:40

License

CC BY

Tags

Creator

Poppy is an interdisciplinary community of beginners and experts, scientists, educators, developers and artists, who all share a vision:
robots are powerful tools to learn and be creative.

The Poppy community develops robotic creations that are easy to build, customize, deploy, and share.
It promotes open-source by sharing hardware, software, and web tools.

The Poppy Project is the work of the research team Flowers from Inria at Bordeaux.
