Spinnerbait Chatterbait Lead / Tin / pewter master mold FISHING LURE

Creation quality: 0.0/5 (0 votes)
Evaluation of members on the printability, utility, level of detail, etc.



3D model description

Master mold, to make silicone molds for three different spinnerbaits and chatterbaits. 3 different sizes.

What you need:

-High temp mold silicone (for example Mold Max 60, or tfc5020)
-lead / tin / pewter (i use Sn60Pb40, it can be cast at 200 degree C, so all you need is a spoon and a candle to heat it)
-2/0 to 4/0 hooks
-0.8 - 1mm spring steel wire for spinnerbait + swivel
-0.5 - 0.6mm wire for softbait holder
-#1 (15mm long) duo lock snap for chatterbaits
-spinner blades, chatter blades (size M, L, XL), 5mm eyes

How to make it:
-print the 2 master parts
-fill the master with silicone and let it cure completely
-remove the silicone mold
-add the hardware like on the picture
-close the mold carefully, so the hardware doesn´t move
-press the molds carefully with clamps
-heat the metal and cast
-let it cool a few minutes
-cut off the cone
-for spinnerbait bend the wire like on the picture and add the blades

Note: the weight can differ for the metal you use.

3D printing settings

layer height as low as possible
line width 0.4mm

3D printer file information

  • Design number: 985039
  • 3D design format: STL Folder details Close
    • 10g (1).stl
    • 10g.stl
    • 13g (1).stl
    • 13g.stl
    • 16g (1).stl
    • 16g.stl

    Learn more about the formats

  • Publication date: 2022-12-30 at 09:58
