Quadruped robot V2.0

3D model description

This is an upgrade for RoboDog V1.0:
https://cults3d.com/en/3d-model/gadget/robodog-v1-0

The base frame stay the say but legs were improved with more solid design, new herringbone gears and additional bearings for servo gears to improve stiffness.

Bearings per leg (4x):
- 4x 693ZZ
- 3x 6704ZZ
- 1x 6706ZZ

Bearings per hip (4x):
- 2x 693ZZ
- 2x 6704ZZ

Useful links:
https://github.com/RoboLabHub/RoboDog_v2
https://www.instructables.com/id/DIY-Spot-Like-Quadruped-Robot/
https://www.instructables.com/id/How-to-Configure-and-Use-Smart-Servos-LewanSoul-LX/

  • 3D file format: STL

Tags

Creator

License

CC BY


Best sellers of the category Gadget


Add a comment

3 comments

Yes, it's a DIY clone of Spot robot for those who don't have $74500 to buy the original one :)

Look like boston dynamics ! nice one !
