Pi Touch Case

?
Creation's quality: 5.0/5 (6 votes)
Evaluation of members on the printability, utility, level of detail, etc.
  • 9.6k views
  • 43 likes
  • 84 downloads

3D model description

Create a kiosk running a raspberry pi, touchscreen, and articulating camera.

(Update 2) Additional STLs without the camera mount by popular demand. All snap-in fan mount sizes included.

(Update 1) Now with snap-in fan mounts to keep your pi cool and other improvements.

After failing to find a well-designed, simple (low part count) kit to run Octopi, that didn't also require a bunch of different screws, I designed the Pi Touch Case. Bring your electronics and 4 M3x10mm screws for the touchscreen’s factory mount and you can be up and running after a single print (considering Prusa i3 Mk3 build size).

Assembly Video:
https://youtu.be/XXRW2bx6Oh0

Printed Components:
- Case
- Stand
- Camera Housing
- Camera Sliding Back
- Camera Mounting Bolt

You Bring:
- Standard 7" Raspberry Pi Touchscreen - https://amzn.to/2BiQGU9
- Compatible Raspberry Pi - https://amzn.to/36Q2hG4
- Pi Camera v2.1 - https://amzn.to/2zHWLcE
- (Optional) Compatible Pi Fan: 30x30x10mm, 40x40x10mm, 50x50x10mm - https://amzn.to/2BgHzDW
- M3x10 Socket Head Screws (4x) - https://amzn.to/2XnCYrJ


3D printing settings

Case Size (Largest Part): 198.97 x 116.79 x 47mm
Build Size of Full Kit (Print Layout Image): 198.97 x 190.52 x 47mm

Layer Height: 0.15mm
Infill: 15%
Perimeters: 3
Bridging: Required
Thin Walls: Required
Supports: None
Brim: None

3D printer file information

  • 3D design format: 3MF and STL Folder details Close
    • camera back.stl
    • camera bolt.stl
    • camera housing.stl
    • camera parts.3mf
    • case (no camera mount) - 30mm screwless fan mount.stl
    • case (no camera mount) - 40mm screwless fan mount.stl
    • case (no camera mount) - 50mm screwless fan mount.stl
    • case (no camera mount) - universal fan mount (screw slots).stl
    • case - 30mm screwless fan mount.stl
    • case - 40mm screwless fan mount.stl
    • case - 50mm screwless fan mount.stl
    • case - universal fan mount (screw slots).stl
    • case and stand - 30mm screwless fan mount.3mf
    • case and stand - 40mm screwless fan mount.3mf
    • case and stand - 50mm screwless fan mount.3mf
    • case and stand - universal fan mount (screw slots).3mf
    • stand.stl
  • Last update: 2020/09/22 at 23:50
  • Publication date: 2020/06/01 at 21:30
