Mini Quadcopter fpv Racer 120mm micro FC lumenier racing F4 Brushless 1103 10.000kv 2S

3D model description

Here is a mini quad racer 120 mm
The kit is composed frame is made of polycarbonate with a soft cockpit in TPU.
The list of components is as follows:

I chose the new fc lumenier F4 ARM:
https://www.drone-fpv-racer.com/lumenier-micro-lux-f4-1308.html

The Quad esc Lumenier 4x10amp bheli s:
https://www.drone-fpv-racer.com/lumenier-esc-10a-4-en-1-blhelis-bb2-dshot-1286.html

With a frsky 8 channel sbus / ppm mini receiver from Banggood:
http://www.banggood.com/FD800-Tiny-Frsky-8CH-PPMSBUS-Receiver-Compatible-FRSKY-ACCST-X9DPlusDJTDFTDHT-For-QX95-QX90-p-1108071.html?rmmds=myorder?p=LD020411878172015024

In Brushless the RacerStar 1103 10.000kv from banggood:
http://www.banggood.com/Racerstar-Racing-Edition-1103-BR1103-10000KV-1-2S-Brushless-Motor-For-100-120-150-RC-Multirotor-p-1110306.html?rmmds=myorder?p=LD020411878172015024

The lipo nacelle is a measure for 500mha bolds from Hobbyking:
https://hobbyking.com/fr_fr/turnigy-bolt-500mah-2s-7-6v-65-130c-high-voltage-lipoly-pack-lihv.html

In VTX the TBS UNIFY PRO 5.8 GHZ V2 - SMA:
https://www.drone-fpv-racer.com/tbs-unify-pro-58-ghz-v2-sma-993.html

With a TBS antenna UNIFY PRO LINEAR ANTENNA 5G8:
http://www.team-blacksheep.com/products/product:984

In Camera a simple 600tvl 110 ° from Banggood:
http://www.banggood.com/600TVL-1_8mm-14-CMOS-120-Degree-Wide-Angle-Lens-FPV-Camera-PALNTSC-3_7-5V-p-1092333.html?rmmds=search?p=LD020411878172015024

2 x M1.6 screws of 16 mm for the lipo fixation
It will be necessary to change the order of the signal cables ESC on the plug when entering the controller.
You will find the correct order in picture 8.
The VTX unify heats very hard, I used a velcro to limit the heat and avoid the flipping of double faces classics

3D printing settings

Printer Brand:
Ultimaker

Printer:
Ultimaker Original

Rafts:
No

Supports:
Yes

Resolution:
0.100mm

Infill:
Polycarbonate / TPU

  • 3D file format: STL
