Mega Cyborg keypad

Creation quality: 5.0/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.



3D model description

Hello! This is keypad with my own design.

23 keys + 2 joysticks.

For assemble you will need:

Countersunk screws:
М3х6 5 pcs.
М3х8 28 pcs.
М3х10 15 pcs.
М3х12 10 pcs.
М3х16 3 pcs.

M2x8 4 pcs.
M3x25 1 pcs.
M3x6 4 pcs.

Pan head screws:
М3х8 10 pcs.
М3х10 4 pcs.
М3х12 5 pcs.

Other details:
Insert nuts 4mm-5mm 64pcs.
Shafts 1.5х10мм 23pcs.
Washers 37mm (1-3pcs.)
M3 nut 1 pcs.

Electronics and more:
1. Teensy++ 2.0 1шт.
2. Omron D2F-01 24pcs.
3. Five way Switch
4. Self-Locking Switch 8mm
5. PCB Screw Terminal Block Connector 10 PIN 5pcs.
6. Nylon Braided Wire Cable sleeve 4 or 6mm (depending on the wires you will use)
7. Multi-colored wires AWG28 (I just took a cable and divided it into separate wires)
8. Heat shrink
9. Quality Dual-axis XY Joystick Module PS2 (OPTIONAL)
10. 2x Diode
11. 2x resistors 220 Om
12. Tap M3.
13. PS4 joystick
14. XBOX elite stick

3D printing settings

Nozzle 0.3, layer 0.15 PLA (resin optional)

3D printer file information

  • Design number: 807042
  • 3D design format: RAR and STL Folder details Close
    • Mega cyborg keypad v3.0.rar

    Learn more about the formats

  • Publication date: 2022-08-08 at 11:37
