Iron Man Mark 5 Helmet

?
Creation's quality: 5.0/5 (4 votes)
Evaluation of members on the printability, utility, level of detail, etc.
  • 👁 8.7k views
  • 65 likes
  • 925 downloads

3D model description

Fully articulated, Wearable, Chargable.
Easy to print, harder to build. Step by step guides are here to help you.

Video Guide:
https://youtu.be/0pcbx-TdSnw
Helmet in Action:
https://youtu.be/f6bQGWkdc1A

What's included:
28 STL files
3 Guides (build, wiring, printing)
1 Code file
1 Parts list

Features:
10 servos driving the action of 10 parts in the facemask.
Single powerbank drives everything and can be recharged while still inside, no batteries needed.
2 power switches, one for Arduino, one for Servos.
Trigger is located in the chin.
Wire management.

Enjoy this build!
If you really enjoyed, consider buying me a coffee:
https://www.buymeacoffee.com/BoxAndLoop

FAQ:
Can I scale this helmet?
No, nope, not a chance.
How big is this helmet? Will it fit my head?
There is a "cage" you can print to test for fit.
Can I see through the eyes?
Yes, but not in the dark.
Can I dim the eyes down?
Not in this version, maybe in the future.
Why do all the servos buzz when the helmet is open?
9g servos are not strong enough to keep everything open without power. Keeping the power to servos creates buzz.
How long does one charge last?
Not sure, but it is in the hours, not in minutes.
How long will it take to print everything?
Depends on your printer and nozzle size. On my Ender 5 with a 0.6mm nozzle, total print time is about 48 hours.
How much filament do I need?
1kg roll should cover it all.

3D printer file information

  • 3D design format: RAR and STL Folder details Close
    • MK5-extra.rar
    • arduino.stl
    • arm_A.stl
    • arm_B.stl
    • arm_Main.stl
    • battery.stl
    • brow_center.stl
    • brow_center_mount.stl
    • brow_main.stl
    • brow_side.stl
    • cheek.stl
    • chin.stl
    • dome01.stl
    • dome02.stl
    • dome03.stl
    • dome04.stl
    • eye.stl
    • jaw.stl
    • mouth.stl
    • nose_center.stl
    • nose_side.stl
    • servoArm_A.stl
    • servoArm_B.stl
    • servoArm_Main.stl
    • wire_back.stl
    • wire_brow.stl
    • wire_cheek.stl
    • wire_main.stl
    • wire_nose.stl

    Learn more about the formats

  • Publication date: 2021/11/09 at 20:13

License

CC BY
