Control Panel

?
Creation's quality: 5.0/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.
  • 1.5k views
  • 3 likes
  • 31 downloads

3D model description

A control panel that holds a power switch, Emergency stop switch, and a 3 segment switch. All made for 110v AC power.

All the connecting hardware are M4x12 bolts with M4 nuts
Supports were used on the box section but may not be needed.
The lid has 2 files. 1 with the raised lettering for use with a CNC machine and a 2nd lid that is blank.

Links the the switches I used
Power Switch = https://amzn.to/33O604O
E-Stop Switch = https://amzn.to/2CEQjkk
3 part switch = https://amzn.to/2CGlwDV

3D printing settings

.2 layer height
3 top,bottom,perimeters
25% infill

  • 3D file format: STL
  • Publication date: 2019/11/14 at 04:02
