3D model description

Hi guys,

the basic idea behind this was to encorporate more tests into dimensions test cube and make improvements to it. So here's what I came up with:

• dimension and clearance test in one print
• 25 mm test cube instead of standard 20 mm so the measuring device tolerance plays lesser of a role
• clearances from 0.2 mm to 0.6 mm
• each cube has clearance marking on the bottom
• 2 versions available - standard and hollowed out for faster printing with wall thickness of 0.9 mm which can be printed with under 3 meters of filament
• 3D printing optimized, no supports required
• chamfered edges - squished first layer can't throw your measurements off now
• after you are succesfully done it turns into fidget spinner

As standard .3mf, .stl, .step and .obj files available!

If you like this design don't forget to like, share, follow and post your makes or you can check out my other projects like this Tetrahedron chainmail fabric:

Lukes3D

Tetrahedron chainmail fabric

• 18.9k views
• 177 likes
• 1.3k downloads
• 0 comments
• 0 makes

Download Free

Cheers!

Luke
