Gills details.stl Download STL file 4-Piece-Swimbait fishing lure 14cm (easy print and build!) • 3D printer design, Domi1988
Head details full.stl Download STL file 4-Piece-Swimbait fishing lure 14cm (easy print and build!) • 3D printer design, Domi1988
Head details lip full.stl Download STL file 4-Piece-Swimbait fishing lure 14cm (easy print and build!) • 3D printer design, Domi1988
Head details lip.stl Download STL file 4-Piece-Swimbait fishing lure 14cm (easy print and build!) • 3D printer design, Domi1988
Head details.stl Download STL file 4-Piece-Swimbait fishing lure 14cm (easy print and build!) • 3D printer design, Domi1988
Mid1 cut fin.stl Download STL file 4-Piece-Swimbait fishing lure 14cm (easy print and build!) • 3D printer design, Domi1988
Mid1 details.stl Download STL file 4-Piece-Swimbait fishing lure 14cm (easy print and build!) • 3D printer design, Domi1988
Mid1.stl Download STL file 4-Piece-Swimbait fishing lure 14cm (easy print and build!) • 3D printer design, Domi1988
Mid2.stl Download STL file 4-Piece-Swimbait fishing lure 14cm (easy print and build!) • 3D printer design, Domi1988
Tail 2piece a.stl Download STL file 4-Piece-Swimbait fishing lure 14cm (easy print and build!) • 3D printer design, Domi1988
Tail 2piece b.stl Download STL file 4-Piece-Swimbait fishing lure 14cm (easy print and build!) • 3D printer design, Domi1988
Tail.stl Download STL file 4-Piece-Swimbait fishing lure 14cm (easy print and build!) • 3D printer design, Domi1988
fin (mirror for second).stl Download STL file 4-Piece-Swimbait fishing lure 14cm (easy print and build!) • 3D printer design, Domi1988
mid2 64%.stl Download STL file 4-Piece-Swimbait fishing lure 14cm (easy print and build!) • 3D printer design, Domi1988
Stencil1.1.stl Download STL file 4-Piece-Swimbait fishing lure 14cm (easy print and build!) • 3D printer design, Domi1988
Stencil1.2.stl Download STL file 4-Piece-Swimbait fishing lure 14cm (easy print and build!) • 3D printer design, Domi1988
Stencil1.stl Download STL file 4-Piece-Swimbait fishing lure 14cm (easy print and build!) • 3D printer design, Domi1988
Stencil2.1.stl Download STL file 4-Piece-Swimbait fishing lure 14cm (easy print and build!) • 3D printer design, Domi1988
Stencil2.2.stl Download STL file 4-Piece-Swimbait fishing lure 14cm (easy print and build!) • 3D printer design, Domi1988
Stencil2.stl Download STL file 4-Piece-Swimbait fishing lure 14cm (easy print and build!) • 3D printer design, Domi1988
tail 64%.stl Download STL file 4-Piece-Swimbait fishing lure 14cm (easy print and build!) • 3D printer design, Domi1988
Mid1 bbs.stl Download STL file 4-Piece-Swimbait fishing lure 14cm (easy print and build!) • 3D printer design, Domi1988
Mid1 details bbs.stl Download STL file 4-Piece-Swimbait fishing lure 14cm (easy print and build!) • 3D printer design, Domi1988
Add to
Make
?
Creation's quality: 5.0/5 (2 votes)
Evaluation of members on the printability, utility, level of detail, etc.
  • 👁 5.9k views
  • 17 likes
  • 15 downloads

3D model description

Easy to print and build swimbait with two different heads. No support, no epoxy needed! 5 minute build time and great action! Build in air chambers. Everything is tested with PLA, PETG, epoxy and no epoxy, and allways runs perfect.

https://www.youtube.com/watch?v=JT66ftDmksM

Including:
-2 different heads (with Lip runs about 3-4 feet deep, without lip runs about 1-2 feet deep.)
-3 different style bodys
-2 different style tails
-2 parts to make a 64% scale version with M1 screws
-6 stencils for painting (they are designed with no tollerances, so please scale them in x and y direction till they fit perfectly. for me it is about 102%)

What you need:
-7x stainless steel screwed eyes M2
EU: https://www.lureparts.nl/de/16mm-oesenschraube-edelstahl.html
US: https://www.lurepartsonline.com/Stainless-Screw-Eyes?quantity=1&custcol_other_style=9&custcol11=308 (size: 3/4" .062" wire and they need to be shortened)
-1x stainless steel screwed eye M1 (for example: https://tinyurl.com/y7khpsse but you will also find them on ebay, etc.)
-1mm stainless spring steel wire
-glue
-6mm sticker eyes

Build instructions see picture!

UPDATE 12.08.2020:
Uploaded the Mid1 part with a hole for 3x 4.5mm bbs, so it runs a bit deeper and even more stable.

3D printing settings

100% Infill!!!!!!
2 outer lines
0.1 - 0.2 mm layer height

3D printer file information

  • 3D design format: STL Folder details Close
    • Gills details.stl
    • Head details full.stl
    • Head details lip full.stl
    • Head details lip.stl
    • Head details.stl
    • Mid1 bbs.stl
    • Mid1 cut fin.stl
    • Mid1 details bbs.stl
    • Mid1 details.stl
    • Mid1.stl
    • Mid2.stl
    • Stencil1.1.stl
    • Stencil1.2.stl
    • Stencil1.stl
    • Stencil2.1.stl
    • Stencil2.2.stl
    • Stencil2.stl
    • Tail 2piece a.stl
    • Tail 2piece b.stl
    • Tail.stl
    • fin (mirror for second).stl
    • mid2 64%.stl
    • tail 64%.stl

    Learn more about the formats

  • Last update: 2020/08/12 at 22:13
  • Publication date: 2020/06/07 at 23:26
