Tamiya Panzer Kampfwagen II Ausf F track upgrade

?
Creation's quality: 0.0/5 (0 votes)
Evaluation of members on the printability, utility, level of detail, etc.
  • 👁 926 views
  • 3 likes
  • 1 download

3D model description

The old Tamiya Panzer Kampfwagen II Ausf F/G is an old classic. One glaring error is the running gear. The tracks are clunky and are mated to a sprocket which has the wrong teeth count.

This set addresses that. This track upgrade includes the individual track which is matched with a sprocket that has the correct teeth count and pitch. It also comes with a detailed idler wheel to complete the look.

Individual track links with matching sprocket and idler wheel. The sprocket has the correct number of teeth and the idler wheel is detailed.
tracks are connected using .3mm copper wire as pins

This set also works for the Dragon kit which also has the wrong sprocket teeth count. A pin is included for DML kits.

The idler wheel comes with two hubs.one for use with Tamiya's polycaps (youll have to cut it down to half) and a solid one if you don't mind gluing the idler wheel to the shaft.


3D printing settings

only for resin printer use!
print at a layer of 0.02mm using supports with a contact diamerter of 0.15mm and a contact depth pf 0.15mm.
sprocket should be supported but oriented face up to preserve the detail. tracks and all other items should be printed at a 45 degree angle.
You will need to print about 230 of the track links which includes the spare tracks mounted at the front of the hull.

3D printer file information

  • 3D design format: STL Folder details Close
    • panzer2-sprocket-adjusted-tam-hub v1.stl
    • panzer2-sprocket-final.stl
    • panzer2-sprocket-pin.stl
    • panzer2-trac-2.57-65.stl
    • panzer2f-idler-wheel v1.stl
    • panzer2f-idler-wheel-hub-v1.stl
    • panzer2f-idler-wheel-hub-v2.stl

    Learn more about the formats

  • Publication date: 2021/11/26 at 20:18

Copyright

©

Tags

Creator

Designs 3
Downloads 5
Sales US$49
Followers 15

I am an RC enthusiast with a background in scale modeling. All my works are made to an exact scale without breaking its proportion. My works are sized for RCs like the Axial SCX10 Deadbolt, Jeep Wrangler JK, HPI FJ Cruiser which are in 1:9 scale and not the published scale of 1:10.

All scale accessories are done in 1:9 scale and when used with 1:9 scaled figures and vehicles, should give you the best scale realism possible. All items are based on real 1:1 items and scaled down proportionately. Scale bodies are also done in this manner and may require narrowing of axles or custom wheelbases. Because we strive to produce perfectly scaled parts, we will not distort or adjust our models just to make them fit the common crawler chassis available in the market.
