Transformer tower EDF HT-MT to BT with 3 types of poles for energy transport

?
Creation's quality: 5.0/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.
  • 2.4k views
  • 4 likes
  • 15 downloads

3D model description

A MV/LV transformation tower from the 1920s and 1960s.

The tower measures 103mm high and has a surface area of 37x37.

The printing will be done in 2 parts (the tower and its frames)

.

In addition, the HV and LV power supply poles are part of the kit.

Assembly and printing documentation provided in pdf format

gcodes are also provided


3D printing settings

PLA 0.1, see pdf for more explanation in Zip
