NAVIGATION BUOYS - N (1/160) SCALE

?
Creation quality: 5.0/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.

3D model description

The model represents a PBM-18 ocean buoy. its diameter in real life is 1.8m and they are commonly used both in calm waters and open sea.

Different types of marks are provided: Marks were designed according the IALA worldwide navigation system.

The model was designed using pictures and detailed drawing of the actual structure in scale 1/160 (N scale). You can resize it using your favourite software before print, however, if you do so, some of the parts may lose stability or look over scaled.

Model has 11 different pieces (2 for the buoy's hull plus 9 different marks) that you need to assembly as any other model kit: I attached an instruction booklet together with the downloaded files.

Printing, painting and weathering will give a lot of fun.
This model can be a great addition to your layout or diorama.

Happy modelling!


3D printing settings

  • Designed to be printed using SLA
  • L12 X W12 X H31 (mm)
  • The widest part measure 12x12mm: **Check your 3dprinter build volume.
  • The kit has 11 parts. 2 for the buoy hull and 9 different interchangeable marks: With the download you get both with and without supports.
  • The supported files are not with the optimal printing orientation but with the optimal orientation according to minimize sanding and provided a perfect fit between parts. However, you can add supports according to your methods.

My printing parameters:
- ANYCUBIC PHOTON MONO X
- Resin ELEGOO standard grey
- Layer height 0.040
- Exposure 1.9 s
- Bottom layer count 6 /25s

Happy modelling!
