E3D V6 for alfawise U20 and U30

I decided to switch to E3DV6, so I created a set for my U20, this one includes:

The support with built-in fang

Hotend cooling fan support

Reducer 40 > 30 if you want to use like me the small fan supplied with the E3D V6, but you can also put a 40 fan.

A cable support.

you will need screws in M3 > 6, 8 and 12 I put you a link if you wish to buy some.

The screws of the old hotend will be used to fix the fan support to the hotend support but you can also put longer screws with a nut on the back, I've planned the location but still in M3.

For the small fan you have to put a small blow of cutter as on the picture.

For the carriage you have to reverse the bottom screw, nut towards the bottom of the machine and cut the screw flush so that it can slide to the endstop of the X.

The fang goes right over the clamps :D

To purchase the screws: https://cutt.ly/AymOqMu

Or: https://cutt.ly/xymOeHL

The heat shrinkable sleeve: https://cutt.ly/aymOurY

The complete Hotend: https://cutt.ly/wymOaNc

If you print it out you can put a little picture as a comment it would be nice :D

Printing in 0.2

20% or more filling

Temperature 205° to be seen according to your wire

60° Tray

Speed 60 mm/s
